Pumping Traps
Condensate Recovery Devices Pumping Traps
GL11-A
Can be used in explosion prevention areas
Features/Applications
Features
Energy saving
Pumping Traps are able to pressure feed low-pressure condensate to high-pressure condensate recovery lines in higher or remote locations. The incorporation of this product enables the previously unused heat energy of condensate to be recovered and efficiently utilized, thus bringing significant benefits in terms of energy saving.
Electricity not required
Pushes condensate out using the pressure of the motive medium*, therefore can easily be installed in ex-proof areas.
No need for additional power grid for remote installations.
*As well as steam, the motive medium can be compressed air, nitrogen gas, or other such gases.
Low filling head
The MIYAWAKI pumping traps have a very low filing head, providing good capacity without the need of higher collectors.
Typical applications
● Recovery of low-pressure condensate (in combination with collectors)
● Support the discharge of condensate from heat exchangers operating close to or below 0 barg
● Stall elimination
*Stall is a phenomenon where the steam trap does not work due to a drop in pressure on the device’s primary side and condensate builds up inside the device. Not only does this prevents the discharge of condensate, it also leads to an increased possibility of water hammer or heat exchanger corrosion occurring.
Dimensions/Weight
Dimensions/Weight
|
Dimensions (mm) |
Maintenance space (mm) |
Dimensions (in) |
Maintenance space (in) |
Weight |
Weight during operation |
||||||||||||||
| H | H1 | H2 | H3 | H4 | D | W | H | H1 | H2 | H3 | H4 | D | W | (kg) | (lb) | (kg) | (lb) | ||
| E | E | ||||||||||||||||||
| 495 | 270 | 154 | 70 | 413 | 325 |
280 |
170 or more | 19.5 | 10.6 | 6.1 | 2.8 | 16.3 | 12.8 | 11.0 | 6.7 or more | 54,0 | 119.1 | 63,0 | 138.9 |
Specifications
| Model | Connection |
Max. operating pressure |
Max. operating temperature |
Motive medium |
||||||
| Type | Size |
PMO (MPa) |
PMO (psig) |
TMO (℃) |
TMO (℉) |
|||||
|
Condensate inlet |
Condensate outlet |
Motive medium Inlet |
Exhaust | |||||||
| GL11-A |
Screwed Rc |
1” |
1” |
1/2” |
1/2” |
1,05 | 152.25 | 185 | 365 |
Steam/air/ nitrogen gas |
●Maximum allowable pressure (PMA): 1,6MPa (at 220℃) (232psig (at 428℉))
●Maximum allowable temperature (TMA): 220℃ (1,6MPa) (428℉ (at 232psig))
●The GL11-A includes the following components.
Check valve CVC3 (body material: stainless steel) 25A (1”) x2
Nipple (material: stainless steel) 25A (1”) x2
*Please be sure to use standard accessories for the check valve.
Flow Capacity Chart
| Filling Head | FH-factors | |
| mm | in | |
| 120 | 4.7 | 0,79 |
| 300 | 11.8 | 0,92 |
| 460 | 18.1 | 1,00 |
| 700 | 27.6 | 1,06 |
| 1000 | 39.4 | 1,11 |
| 1100 | 43.3 | 1,12 |
Installation Examples
Download
* Membership registration is required to download the documents.
