Blowdown Valves

Ancillary Equipment Blowdown Valves VB1/VB1R

Ancillary Equipment Blowdown Valves

VB1/VB1R

  • SCCV System
  • Stainless Steel
  • Supports condensate recovery
  • Horizontal installation
  • Vertical installation
  • Bypass function
  • Automatic air venting
    Ancillary Equipment Blowdown Valves VB1/VB1R

    Features/Applications

    Features

    • Compact and lightweight design

    • Removes dirt and scales in the screen of steam traps

    Typical applications

    Suitable for using to the screen plug of steam traps

    Dimensions/Weight

    Dimensions/Weight




    Model Size Dimensions (mm) Dimensions (in) Weight
    L W L W (kg) (lb)
    VB1 1/4” 46 23 1.8 1.0 0,08 0.2
    VB1R 50 2.0

    Specifications

    Model Connection

    Max. operating

    pressure

    Max. operating

    pressure differential

    Max. operating

    temperature

    Body

    material

    Type Size (MPa) (psig) (MPa) (psig) (℃) (℉)
    VB1

    Screwed
    G (Parallel male screw)

    1/4” 6,4 928 6,4 928 425 797

    Stainless steel

    SUS403

    VB1R Screwed
    R (Tapered male screw)

    Flow Rate

    VB1


    Download

    * Membership registration is required to download the documents.

    Features

    • Compact and lightweight design

    • Removes dirt and scales in the screen of steam traps

    Typical applications

    Suitable for using to the screen plug of steam traps

    Dimensions/Weight




    Model Size Dimensions (mm) Dimensions (in) Weight
    L W L W (kg) (lb)
    VB1 1/4” 46 23 1.8 1.0 0,08 0.2
    VB1R 50 2.0
    Model Connection

    Max. operating

    pressure

    Max. operating

    pressure differential

    Max. operating

    temperature

    Body

    material

    Type Size (MPa) (psig) (MPa) (psig) (℃) (℉)
    VB1

    Screwed
    G (Parallel male screw)

    1/4” 6,4 928 6,4 928 425 797

    Stainless steel

    SUS403

    VB1R Screwed
    R (Tapered male screw)

    VB1


    * Membership registration is required to download the documents.
